| Brand Name: | LightlinK |
| Model Number: | P3.91 |
| MOQ: | 1 |
| Payment Terms: | L/C,D/A,T/T,Western Union |
| Parameter Category | Technical Specification | Details and Description |
|---|---|---|
| Basic Specifications | Pixel Pitch | 3.91 mm |
| Cabinet Size | 500 mm × 500 mm (Common size for easy installation and maintenance) | |
| Cabinet Resolution | 128 × 128 pixels | |
| Pixel Density | 65,536 pixels per square meter | |
| Display Performance | Brightness | ≥ 600 cd/m² (Manually adjustable to suit various indoor lighting conditions) |
| Refresh Rate | ≥ 3840 Hz (Flicker-free, ensures smooth playback even when recorded by high-speed cameras) | |
| Gray Scale | 16-bit (Delivers superb color gradation and deep, true blacks) | |
| Viewing Angle | Horizontal 160° / Vertical 160° (Provides a clear and consistent image from virtually any position in the room) | |
| Color & Image | Color Temperature | Adjustable from 1000K to 10000K |
| Color Gamut | Covers ≥ 110% NTSC standard (Producing vibrant and accurate colors) | |
| Contrast Ratio | ≥ 5000:1 (Enhances image sharpness and detail) | |
| System & Control | Drive Method | Constant current drive |
| Control System | Compatible with mainstream control systems, supporting synchronous and asynchronous playback | |
| Input Signal | Supports HDMI, DVI, SDI, network streaming, etc. | |
| Reliability & Power | Power Consumption | Average approx. 350W/㎡, maximum under 700W/㎡ |
| MTBF | > 10,000 hours | |
| Life Span | ≥ 100,000 hours |
