| Nom De La Marque: | GLOSHINE |
| Numéro De Modèle: | CFPL |
| Nombre De Pièces: | 1 |
| Conditions De Paiement: | D / A, L / C, T / T, Western Union |
| Capacité à Fournir: | 600 |
The CF series features an integrated modular design with quick side locks. It supports curved installation with a maximum angle of ±30°. A single cabinet can achieve a perfect "S" shape and supports rear maintenance.
The PL series represents simplicity and practicality. Every detail reveals its ultimate and practical personality. It can be flexibly combined with the CL/CF series to create a variety of styles.
| Parameter | CF 1.95 (Indoor) | CF 2.60 (Indoor) | CF 2.97 (Indoor) | CF 3.91 (Indoor) |
|---|---|---|---|---|
| Pixel Pitch | 1.95mm | 2.60mm | 2.97mm | 3.91mm |
| LED Model | SMD1212 | SMD1515 | SMD2020 | SMD2020 |
| Pixel Density | 262144 pixel/m² | 147456 pixel/m² | 112896 pixel/m² | 65536 pixel/m² |
| Brightness | 600-900 nits | 800-1300 nits | 1000-1300 nits | 1000-1300 nits |
| Color Temperature | 6500-9500K | 6500-9500K | 6500-9500K | 6500-9500K |
| Scan Mode | 1/32 | 1/24 | 1/21 | 1/16 |
| Cabinet Size | 500mm × 500mm × 94mm (all models) | |||
| Cabinet Resolution | 256 × 256 pixel | 192 × 192 pixel | 168 × 168 pixel | 128 × 128 pixel |
| Cabinet Weight | 8.5 kg | 8.5 kg | 8.5 kg | 8.5 kg |
| Cabinet Material | Die-cast Aluminum | |||
| Max. Power Consumption | ≤ 720 W/m² | ≤ 720 W/m² | ≤ 680 W/m² | ≤ 680 W/m² |
| Average Power Consumption | ≤ 360 W/m² | ≤ 360 W/m² | ≤ 350 W/m² | ≤ 350 W/m² |
| Viewing Angle | H:160° V:140° | |||
| Refresh Rate | 1920Hz / 3840Hz | |||
| Grayscale | 13-16 bit | |||
| Protection Rating | IP30 | |||
| Lifespan | 50,000 hours | |||
| Max. Stacking/Hanging | 10 pcs | |||
| Operating Temp./Humidity | -20°C ~ +45°C; 10% - 60% RH (all models) | |||
| Storage Temp./Humidity | -40°C ~ +60°C; 10% - 60% RH (all models) | |||
